Tension Leveler

Features and applications

To eliminate wave shapes and adjust functions of cold rolled coils through ways of two bending and one straightening or two bending and two straightening. If necessary,the static coating oil machine could be deployed,which can make coils clean and flat.It is applicable for enterprises who roll common steel,stainless steel,copper and aluminum coils.

Components

Uncoiling → two rollers transmission → hydraulic shear → welder → entry “S”roller → Bending straightening → exit “S”roller → oil coating machine → hydraulic shear → Coiler(floating)


Technical parameters


Roller length 600 800 1000
Strip width 350-500 550-700 750-900
Strip thickness 0.2-1.2 0.2-1.2 0.2-1.2
Extension rate 0.5-3%

Roller length 1200 1450
Strip width 950-1100 1100-1300
Strip thickness 0.2-1.2 0.2-1.2
Extension rate 0.5-3%
